Lead Acid VS. Wall Mounted lifepo4 battery. What is the greatest off-grid option?
Introduction
Now battery storage is becoming an increasingly popular addition to solar energy systems. Two of the most common types of chemical batteries are lithium and lead-acid. As the name suggests, lithium batteries are made from lithium metal, while lead-acid batteries are mainly made from lead and acid. As our wall-mounted powerwall is powered by LiFePO4 cell, we’ll make a comparison between these two--powerwall vs lead-acid.
Analysis from an expert's perspective !
1. Electricity and voltage.
provides a little different nominal voltage, which actually makes it a better fit for replacing lead-acid batteries.● A comparison of these two types of electricity
Batteries made of lead-acid: 12V*100Ah = 1200WH; 48V*100Ah = 4800WH
LiFePO4 solar battery: 12.8V*100Ah = 1280KWH; 51.2V*100Ah = 5120WH;
● When compared to a product with a comparable rating for lead acid, lithium iron phosphate batteries have a higher useful capacity. Up to twice as much run time is anticipated.
2. Life cycle.
● We will now just discuss the wall mounted LiFePO4 solar battery's cycle life while the lead-acid battery's cycle life may already be extremely familiar to you..
It is capable of exceeding 2000 cycles at 100% DOD and 4,000 cycles at 80% DOD.
LiFePO4 battery can be fully depleted without risk of harm in the meantime.
After discharging your battery, be careful to charge it right away. To prevent the BMS from disconnecting the battery, we advise restricting discharge to 80–90% depth of discharge (DOD).
3. Powerwall Guarantee Compared to Lead-Acid
The ROYCE Powerwall comes with a 5-year guarantee with a possible 10-year extension since its internal software carefully analyzes its batteries' rate of charge, discharge, voltage levels, temperature, percentage of the world conquered, and so on in order to maximize their lifespan. In the meantime, lead-acid battery manufacturers only provide one-year warranties, or possibly two if you're prepared to pay extra for a more expensive model, because they have no control over how you will utilize their products. The biggest benefit that the Powerwall has over its rivals is this. The majority of individuals, especially those in the business world, are merely reluctant to commit a sizeable sum of money to a new venture unless they are certain that they won't lose money in the event that something goes wrong. If I had to choose solely lead-acid batteries, I would definitely spend a lot more for those that had a ten-year guarantee.4. The temperature.
● Most tropical regions can use LiFePO4 battery because it can withstand a larger range of temperatures during discharging.
● Lead acid battery ambient temperature range: -4°F to 122°F
● LiFePO4 wall mounted solar battery ambient temperature range: -4°F to 140°F
Additionally, because LiFePO4 battery have BMS built in, they can withstand higher temperatures while remaining safer than lead-acid batteries. There won't be any heat produced because this technology can recognize abnormal temperatures in advance, preserve the battery, and automatically cease charging or discharging.
5. Powerwall vs Lead-Acid Storage Capacity
Because lead-acid batteries and Powerwalls have different capacities, it is not possible to compare them directly. If I were to spend $3,800 on a 7-kilowatt-hour Powerwall, I could purchase approximately 17 kilowatt-hours of lead-acid batteries with a good lifespan. However, their actual storage capacity is limited to 13.6 kilowatt-hours because they cannot be discharged by greater than 80%. Moreover, I will need to refrain from draining them more than 25% each night if I want them to last 15 years. As a result, they essentially only have 4.25 kWh of storage for the majority of the year. Therefore, the Powerwall is better for daily usage; yet, when necessary, lead-acid batteries can be more deeply depleted to supply electricity during inclement weather or times when demand for electricity is high. However, if you do this too frequently, it will ruin them.
6. Price.
LiFePO4 battery will cost more than lead-acid batteries as they do now, therefore initial investment will be more. However, you'll discover that LiFePO4 battery perform better.
If you provide us the specifications and price of the batteries you are using, we may share the comparison table for your reference. after determining the daily unit price (USD) for two different kinds of batteries.
You will discover that the unit price/cycle of LiFePO4 battery is less than that of lead-acid batteries.
7. An impact on the surroundings.
We all want to do our share to lessen pollution and resource consumption because we care about saving the environment. LiFePO4 battery are a great option for allowing renewable energy sources like solar and wind and for reducing the negative effects of resource extraction when it comes to battery technology.
8. Powerwall Effectiveness
Compared to lead-acid batteries, which have an energy storage efficiency of about 85%, a Powerwall has a much higher efficiency of 92%. While it doesn't make a significant impact in real life, it does assist. To fully charge a Powerwall with 7 kilowatt-hours of solar electricity—roughly half the usual daily production of one solar panel—it will require between half and two-thirds of a kilowatt-hour less solar electricity than lead-acid batteries.
9. Space Encroachers
The Powerwall is designed to be put on walls and can be installed both indoors and outdoors. It also takes up very little room. When deployed correctly, it ought to be quite secure. Lead-acid batteries can be installed indoors provided appropriate safety measures are taken, but I strongly advise installing them outdoors owing to the very slim but actual possibility that a lead-acid battery will decide to turn into a fiery pile of fuming ooze. Though larger than what Powerwalls require, the amount of space needed for enough lead-acid batteries to power an off-grid home is not as large as many people believe. A bank of lead-acid batteries of the size of a single bed, the thickness of a dinner plate, and roughly the height of a bar fridge could be needed to power a two-person home off the grid. While not every installation requires a battery enclosure, care must be taken to keep kids from stress testing the system or the other way around.
10. Maintains
Every six months, sealed long-life lead-acid batteries need a little bit of maintenance. There is none needed for the Powerwall.
If 80%DOD is the basis for a battery that has more than 4000 cycles;
Should you like to charge the battery in one to two hours;
If you wish to reduce the lead-acid battery's weight and space consumption...
Accept the LiFePO4 powerwall option and move forward. Like you, we think going green is important.
